5A DC Motor PWM Speed Control – 3V, 6V, 12V, 24V, 35V

5A DC Motor PWM Speed Control – (3V, 6V, 12V, 24V, 35V) is a Mini Style DC Motor Speed Regulator controls the speed of a DC motor by adjusting Pulse-Width-Modulated (PWM). Precautions: DC motor governor input is DC, can not directly connect to the AC (for example home 220V AC), otherwise, it will burn! DC power supply positive and negative terminals do not reverse, otherwise, the governor may be damaged. The motor can be positive or negative when the direction of operation and expectations do not match, you can adjust the line order to change the direction. Adjust the potentiometer knob to change the governor output duty cycle, the motor speed changes. Technical Specifications: Mini DC 4.5-35V 5A PWM Motor Speed Controller. Wide voltage DC motor speed controller. Operating voltage: DC4.5V-35V Output current: 0-5A Output power: 90W (max) PWM duty cycle: 1% -100%. Operating voltage: DC 4.5V-35V Quiescent current: 7uA (standby) PWM frequency: 20khz Package Includes: 1 Piece–5A DC Motor PWM Speed Control – 3V, 6V, 12V, 24V, 35V
